IG-42 GP

SSI: IGR:005

SSI: IGR:005

Technical Specifications
Main Material	Aluminium, Copers, SS, Nylon
Work Pressure	0.02 - 0.7MPa
Usage	Agriculture, Forestry, Garden
Flow	22.2 - 92.8m³/h
Connector Size	2 Flange
Radius	31 - 63.5m
Spray Angle	24°
Sprinkler Type	360° Gear Adjustable

Quantity:

Nozzle Diameter	Pressure	Flow	Range
mm	MPa	m³/h	m
20	0.2	22.2	31.0
	0.3	26.7	36.0
	0.4	31.5	41.2
	0.5	35.1	44.0
	0.6	38.1	47.1
	0.7	42.2	49.0
22	0.2	26.8	33.0
	0.3	33.5	37.5
	0.4	37.9	43.0
	0.5	42.5	46.0
	0.6	46.5	49.5
	0.7	49.8	52.0
24	0.2	31.8	34.0
	0.3	39.5	40.0
	0.4	45.3	44.3
	0.5	50.3	48.0
	0.6	54.6	52.0
	0.7	58.8	55.2
26	0.2	37.5	36.6
	0.3	45.7	42.0
	0.4	52.3	47.0
	0.5	58.9	51.5
	0.6	64.5	55.0
	0.7	69.0	58.0
28	0.2	43.2	37.0
	0.3	52.7	43.0
	0.4	61.1	49.0
	0.5	67.8	53.2
	0.6	74.6	57.0
	0.7	81.0	60.0
30	0.2	49.3	39.0
	0.3	60.5	45.0
	0.4	70.0	51.0
	0.5	78.0	55.8
	0.6	85.7	59.0
	0.7	92.8	63.5
